Measure Chainsaw Chain Size: A Simple Guide

Hey there, fellow DIY enthusiasts and outdoor warriors! Ever found yourself scratching your head, trying to figure out the size of your chainsaw chain? You're not alone, guys! Chainsaw chains can seem a bit mysterious, with their unique sizing system. But don't worry, this guide will break it all down for you in a way that's super easy to understand. We'll cover everything from pitch and gauge to drive links, and show you exactly where to find these measurements on your chainsaw. So, grab your tools, and let's get started on demystifying the world of chainsaw chain measurements!

Understanding Chainsaw Chain Measurements

When it comes to chainsaw chains, size matters! But instead of a single measurement, like you might find with other tools, chainsaw chains have three crucial dimensions: pitch, gauge, and the number of drive links. Understanding these three measurements is the key to ensuring you get the right replacement chain for your saw. Let's dive into each one:

Pitch: The Spacing of the Teeth

First up, we have the pitch, which essentially tells you how closely the teeth are spaced on the chain. Think of it as the chain's tooth density. The pitch is defined as the distance between any three consecutive rivets divided by two. Rivets are the little round metal pieces that hold the chain segments together. Now, doing the actual measurement can be a bit tricky, so manufacturers have made it easier for us. The pitch is usually expressed in inches, and you'll commonly see sizes like 0.325 inch, 3/8 inch (0.375 inch), or 0.404 inch.

Why is pitch important? Well, the pitch needs to match the sprocket on your chainsaw. The sprocket is the toothed wheel that drives the chain around the bar. If the pitch of the chain doesn't match the sprocket, the chain won't fit properly, and your saw won't work. It's like trying to fit a square peg in a round hole – it's just not going to happen!

How to find the pitch: The easiest way to find the pitch is usually by looking at the chainsaw bar itself. Many bars have the pitch stamped right on them. You can also find this information in your chainsaw's user manual. And if all else fails, you can always measure the distance between three rivets and divide by two, but trust me, checking the bar or manual is way simpler!

Gauge: The Thickness of the Drive Links

Next, we have the gauge, which refers to the thickness of the drive links. Drive links are the little teeth-like parts of the chain that fit into the groove on the chainsaw bar. The gauge measurement tells you how wide these drive links are. Gauge is typically expressed in thousandths of an inch, such as 0.043 inch, 0.050 inch, 0.058 inch, or 0.063 inch.

Why is gauge important? The gauge is crucial because it needs to match the width of the groove in your chainsaw bar. If the gauge is too small, the chain will be loose and wobbly, which is not only inefficient but also dangerous. If the gauge is too large, the chain won't fit into the groove at all. It's like trying to wear shoes that are either way too big or way too small – neither option is going to work!

How to find the gauge: Just like with pitch, the gauge is often stamped on the chainsaw bar. Look for a number expressed in thousandths of an inch. You can also find this information in your chainsaw's user manual. Sometimes, the gauge might be harder to spot than the pitch, so take your time and look carefully. A magnifying glass can be your friend here!

Drive Links: The Number of Teeth That Fit into the Bar

Finally, we have the number of drive links. This is simply the count of the small, tooth-like links on the chain that fit into the groove of the chainsaw bar. Think of these as the little feet that propel the chain around the bar. The number of drive links is a whole number, like 52, 56, 60, etc.

Why are drive links important? The number of drive links determines the length of the chain. You need the correct number of drive links to ensure the chain fits snugly around your chainsaw bar. If you have too few drive links, the chain will be too short and won't reach all the way around the bar. If you have too many, the chain will be too loose and could potentially come off while you're cutting – a big no-no!

How to find the number of drive links: This one is pretty straightforward – you just need to count them! Lay your chain out on a flat surface and count each drive link. It might seem tedious, but it's an essential step. Alternatively, the number of drive links is often stamped on the chainsaw bar, usually right next to the pitch and gauge information. This is definitely the easier option if you can find it!

Locating Chain Measurements on Your Chainsaw

Okay, now that we understand what pitch, gauge, and drive links are, let's talk about where to find these measurements on your chainsaw. Fortunately, manufacturers usually make it pretty easy for us. The most common place to find this information is on the chainsaw bar itself.

Checking the Chainsaw Bar

The chainsaw bar is the metal blade that the chain runs around. Take a close look at the bar, especially near the base where it connects to the chainsaw body. You'll often find a series of numbers and symbols stamped or printed on the bar. These markings usually include the pitch, gauge, and the number of drive links. They might be abbreviated or use symbols, but once you know what to look for, they're pretty easy to decipher.

For example, you might see something like "3/8 .050 68DL". This would indicate a pitch of 3/8 inch, a gauge of 0.050 inch, and 68 drive links. Sometimes, the "DL" for drive links is omitted, and you'll just see the number. The key is to look for three numbers – one expressed as a fraction or decimal (pitch), one in thousandths of an inch (gauge), and one whole number (drive links).

Pro Tip: If the markings on your bar are worn or faded, you might need to clean the bar with a wire brush or some sandpaper to make them more visible. Be careful not to damage the bar in the process!

Consulting Your Chainsaw's User Manual

Another reliable source of information is your chainsaw's user manual. This little booklet is packed with all sorts of helpful details about your saw, including the recommended chain size. Check the specifications section of the manual, and you should find the pitch, gauge, and the number of drive links listed. The manual might also provide alternative chain sizes that are compatible with your saw, which can be useful if you're looking for different cutting performance.

Pro Tip: If you've misplaced your user manual, don't panic! Many manufacturers have digital versions of their manuals available on their websites. Just search for your chainsaw's make and model, and you should be able to find a downloadable PDF.

When in Doubt, Count and Measure!

If you can't find the measurements on the bar or in the manual, or if you just want to double-check, you can always measure the chain yourself. We've already talked about how to measure the pitch (distance between three rivets divided by two) and count the drive links. To measure the gauge, you'll need a set of calipers or a gauge measuring tool, which you can find at most hardware stores. These tools allow you to accurately measure the thickness of the drive links.

Pro Tip: If you're not comfortable measuring the chain yourself, or if you're unsure about the results, it's always best to take your chainsaw to a qualified service technician. They'll be able to identify the correct chain size and ensure you get the right replacement.

Why Getting the Right Chain Matters

You might be thinking, "Okay, I know how to find the measurements, but why is it so important to get the right chain?" Well, guys, using the wrong chainsaw chain can lead to a whole host of problems, ranging from poor cutting performance to serious safety hazards. Let's take a look at some of the key reasons why getting the right chain matters:

Safety First!

This is the most important reason of all. Using the wrong chain can significantly increase the risk of accidents. A chain that's the wrong size or doesn't fit properly can be more prone to kickback, which is when the chainsaw suddenly jumps back towards you. Kickback can cause serious injuries, so it's crucial to use a chain that's specifically designed for your saw and bar.

Additionally, a loose or improperly fitted chain is more likely to come off the bar while you're cutting. A flying chain is incredibly dangerous and can cause severe cuts or even worse. So, for your own safety and the safety of those around you, always use the correct chain.

Optimal Cutting Performance

Using the right chain ensures that your chainsaw operates at its peak performance. A properly fitted chain will cut smoothly and efficiently, making your work easier and faster. If the chain is too loose or too tight, it can cause the saw to vibrate excessively, which can be uncomfortable and tiring to use. It can also put unnecessary strain on the engine and other components, potentially shortening the lifespan of your chainsaw.

Preventing Damage to Your Chainsaw

Using the wrong chain can also damage your chainsaw. A chain that doesn't fit properly can put undue stress on the bar, sprocket, and engine. This can lead to premature wear and tear, and in some cases, even cause parts to break. Repairing a chainsaw can be costly, so it's much better to invest in the right chain from the start.

Ensuring Compatibility and Fit

As we've discussed, the pitch, gauge, and number of drive links need to match your chainsaw's specifications. If any of these measurements are incorrect, the chain simply won't fit properly. It's like trying to put the wrong battery in a device – it just won't work. Getting the right chain ensures that it fits snugly on the bar, meshes correctly with the sprocket, and operates smoothly.

Tips for Buying a Replacement Chain

Okay, so you know how to measure your chain and why it's important. Now, let's talk about buying a replacement chain. Here are a few tips to keep in mind:

Write Down Your Measurements

Before you head to the store or shop online, make sure you have your measurements written down. This will prevent you from forgetting them or mixing them up. Note down the pitch, gauge, and the number of drive links. It's also a good idea to note the make and model of your chainsaw, as some chains are specifically designed for certain models.

Take Your Old Chain with You (If Possible)

If you still have your old chain, bring it with you when you go shopping. This can be helpful for comparison purposes, especially if the markings on your bar are difficult to read. The staff at the store can often use your old chain to identify the correct replacement.

Consider the Type of Chain

Chainsaw chains come in different types, each designed for specific cutting applications. For example, some chains are designed for fast cutting, while others are better for cutting hardwoods. Consider the type of cutting you'll be doing most often and choose a chain that's appropriate for your needs. Common chain types include:

• Full chisel chains: These have square-cornered teeth and are known for their fast cutting speed. They're best suited for experienced users and clean wood.
• Semi-chisel chains: These have rounded-corner teeth and are more forgiving than full chisel chains. They're a good choice for general-purpose cutting and can handle dirty or knotty wood better.
• Low-kickback chains: These chains have special features that reduce the risk of kickback. They're a good choice for beginners or anyone who prioritizes safety.

Buy from a Reputable Source

It's always a good idea to buy your replacement chain from a reputable source, such as a hardware store, outdoor equipment dealer, or a trusted online retailer. This will help ensure that you're getting a high-quality chain that's properly manufactured and will perform well.

Don't Be Afraid to Ask for Help

If you're unsure about which chain to buy, don't hesitate to ask for help from the staff at the store. They can answer your questions and help you find the right chain for your chainsaw.

Final Thoughts

So, there you have it, guys! Everything you need to know about how to measure a chainsaw chain. It might seem a bit complicated at first, but once you understand the basics of pitch, gauge, and drive links, it becomes much easier. Remember, getting the right chain is crucial for safety, performance, and the longevity of your chainsaw. So, take your time, measure carefully, and don't hesitate to ask for help if you need it. Happy cutting!
